Real words or buzzwords?: Open

March 28, 2017
Though commonly used in the industry, 'open' can mean different things to different people

The word "open" is usually used in conjunction with other words, most commonly Open Architecture and Open Platform in the physical security industry. They appear in product promotional materials, manufacturer Architect and Engineer (A&E) product specifications, as well as in the system performance specifications of design-build projects.

These terms are commonly used in IT and many other fields, and in each field their definitions are adjusted as people apply the concept of “open” to their technology designs and strategies. This is why internet searches on these terms don’t lead to clarity for integrators, consultants, and end-user customers of the security industry. There are many valid variations on what these terms mean, but none of them help us if we don’t know and apply the right ones.

At this writing, a Google search for “open system architecture” (including the quotes) provided about 193,000 results—yielding a much wider range of definitions than I had expected. Yet the answers we need are there, buried in a hundred thousand articles and book references. Some of them are pure gold, including the IT definition of “Open System” provided later in this article.

Clarity for Manufacturers

In the IT world, the degree and nature of “openness” are treated as strategic product considerations, as they do have a significant impact on a product’s position in the marketplace and its value to end customers as well as industry partners. Amazing results have come from ensuring that development teams achieve crystal clarity on these terms and everyone getting on the same page. These terms are critically important from the perspective of product business strategy, and there are profit-and-loss case study examples available on the internet that are very revealing.

But more pertinent to this article, is this tip to manufacturers: you should realize that if your customers can’t explain what these terms mean—as appear in your literature—then your use of them is meaningless. And if your sales people can’t give meaningful answers, whatever open features you are proud of will work against you.

Therefore, manufacturers and their product development teams need to take a very close look at how those terms should be applied not only in the design and development of products and systems, but in the explanations that they provide to sales people, channel partners and customers.

System Purchasers, Designers and Providers

Do all manufacturers mean the same thing when they say their product or system is “open?” Definitely not. Can consultants and end users tell you exactly what they mean when they say “open platform” in their specifications? Not when I’ve asked the question. And I have yet to find a product or A&E specification that includes a definition of Open Platform, Open Architecture or Open System in a specification’s “Part 1” list of definitions.

As we begin developing and deploying security systems as evolvable intelligent infrastructure, there are several concepts of open system architecture that apply.

Open Systems Architecture

I have extracted applicable concepts from two definitions as provided to us by Federal Standard 1037C, the Glossary of Telecommunication Terms.

Definition: 1. The layered hierarchical structure, configuration, or model of a communications or distributed data processing system that:

a) enables system description, design, development, installation, operation, improvement, and maintenance to be performed at a given layer or layers in the hierarchical structure,

b) allows each layer to provide a set of accessible functions that can be controlled and used by the functions in the layer above it,

c) enables each layer to be implemented without affecting the implementation of other layers, and

d) allows the alteration of system performance by the modification of one or more layers without altering the existing equipment, procedures, and protocols at the remaining layers.

Examples of independent alterations include a) converting from wire to optical fibers at a physical layer without affecting the data-link layer or the network layer except to provide more traffic capacity, and (b) altering the operational protocols at the network level without altering the physical layer.

2. Nonproprietary systems architecture.

This is a telecommunications system example, but you can see how the concept of system layer independence can be an important one. The layered system design concept is a highly applicable design model, especially when considering the availability of global networking, the advent of truly intelligent buildings, and the pervasive IoT device network that is rapidly evolving.

Applying Open Systems Architecture Concepts

It is important to realize that high-level design for our security systems will, very shortly, need to integrate with a multitude of external systems and devices that will provide real-time information and provide real-time control that extend outside of the traditional boundaries of our security system deployments. Device and system products that are “open” (which we’ll consider more closely below) will be required to build the kind of security system infrastructures appropriate for today’s world.

IT World Definitions of Open

There are definitions of Open Architecture and Open Platform that are applicable to security industry technology because today’s security devices and systems are based on information technology (computing, database, networking and user interaction technology).

Open Architecture

Definition: An architecture whose specifications are public. This includes officially approved standards as well as privately designed architectures whose specifications are made public by the designers. The opposite of open is closed or proprietary.

The great advantage of open architectures is that anyone can design add-on products for it. By making an architecture public, however, a manufacturer may be allowing others to duplicate its product.

Open Platform

Definition: In computing, an open platform describes a software system that is a) based on open standards, such as published and fully documented external application programming interfaces (API) based on protocol standards and that b) allow using the software to function in other ways than the original programmer intended, without requiring modification of the source code. Using these interfaces, a third party could integrate with the platform to add functionality.

Only the first part of this definition applies to current security industry systems that are being labelled as Open Platform. PSIM (Physical Security Information Management) products utilize existing security products and platform that conform to the first of the Open Platform definition above.

An open platform of this type implies that the vendor allows, and perhaps supports, the ability to create new functionality and to use the platform in ways not previously conceived. Using such an open platform, a developer could add features or functionality that the platform vendor had not completed or had not conceived of.

A service-oriented architecture (SOA) allows applications, running as services, to be accessed in a distributed computing environment, such as between multiple systems or across the Internet. A major focus of web services is to make functional building blocks accessible over standard Internet protocols that are independent from platforms and programming languages. An open SOA platform would allow anyone to access and interact with these building blocks.

Despite the limitations of existing security systems technology, there are some bright minds that are thinking along the lines of the second part of this definition in order to create innovative security products.

Open Products and Systems

There are several definitions of “open” that apply to security products and systems, and it is possible to reduce the resulting confusion by categorizing and ranking them in a way that enables better security system design thinking and planning. Thus, I developed the scale below for ranking the open capabilities of products and systems. Note that even a highly proprietary system can still be open in ways that are valuable.

Customers, consultants and integrators should nudge vendors in the direction of being “open” based upon the security operations capabilities that such development would provide. Product advancement can be envisioned using the scale below.

Each level of ranking includes one version or another of the levels below it. Note that this is intended to be a simple and practical scale, and so it is not complicated by other possible rating factors such as cybersecurity capabilities, which are also important but can be evaluated independently of the openness factors.

An Openness Scale

  • Evolvable Interaction. A device or system whose providers or end-users can define, configure and set up two-way interaction with other systems using only the system’s front-end user interface, enabling users to vary and expand the interactions as their technology infrastructure grows and evolves.
  • Interaction by Design. A system structured to encourage interaction by other systems.

- Available to any provider or owner using standards-based protocols.
- Available to any provider or owner using proprietary but well-documented protocols.
- Available only to licensed partners using standards-based protocols
- Available only to licensed partners using proprietary protocols

  • Two-Way Interaction. A device or system designed to allow two-way interaction with other products and systems.
  • One-Way Interaction. A device or system designed to allow one-way interaction with other products and systems.
  • Closed. Not designed for interaction with other products or systems.

Use this scale to rate your existing security system infrastructure, as well as the new products that you encounter.

Example of Good Documentation

One example of good documentation is Milestone’s Open Platform page describing exactly what Milestone means by Open Platform. It’s great when manufacturers also go one step further than documentation, by providing training and engineering support for integration projects, which is usually done as part of a partner program.

About the Author:

Ray Bernard, PSP CHS-III, is the principal consultant for Ray Bernard Consulting Services (RBCS), a firm that provides security consulting services for public and private facilities (www.go-rbcs.com). He is the author of the Elsevier book Security Technology Convergence Insights available on Amazon. Mr. Bernard is a Subject Matter Expert Faculty of the Security Executive Council (SEC) and an active member of the ASIS International member councils for Physical Security and IT Security.

About the Author

Ray Bernard, PSP, CHS-III

Ray Bernard, PSP CHS-III, is the principal consultant for Ray Bernard Consulting Services (www.go-rbcs.com), a firm that provides security consulting services for public and private facilities. He has been a frequent contributor to Security Business, SecurityInfoWatch and STE magazine for decades. He is the author of the Elsevier book Security Technology Convergence Insights, available on Amazon. Mr. Bernard is an active member of the ASIS member councils for Physical Security and IT Security, and is a member of the Subject Matter Expert Faculty of the Security Executive Council (www.SecurityExecutiveCouncil.com).

Follow him on LinkedIn: www.linkedin.com/in/raybernard

Follow him on Twitter: @RayBernardRBCS.
