OSD Debuts New Monitor for Handheld Applications

Nov. 16, 2006
3.5-inch QVGA TFT display uses white LED backlight

OSD Displays (OSD) - Winter Park, FL. has announced another innovative active matrix TFT-LCDs for hand-held consumer and industrial applications.

The OSD0345CA6T1 is a 3.45" diagonal transmissive QVGA TFT with White LED backlight and with or without integrated resistive touchscreen.

The OSD0345CA6T1 boasts a high performance long-life White LED backlight. It offers an initial typical brightness of 320 cd/m2 with 40k hours of service life.

The display has a 24-bit RGB interface and can support up to 16.7M colors.

CCIR601/656 interface is also supported.

Overall dimensions are 76.9mm x 63.9 mm x 4.4mm, with an active area of 53.28mm x 71.04mm.

The display features a 200:1 contrast ratio with the backlight on.

This display module integrates LCD control functions using Chip-On-Glass (COG) technology to create a space-efficient, reliable, low-power module. Chip-On-Glass (COG) construction allows the driver ICs to be mounted directly to the LCD panel reducing the overall component count and mechanical footprint.

Volume pricing for 5k per lot is US$25.00 or less. OSD Displays is online at www.osddisplays.com.
